WCMI Barcode Access Control Door NFC Reader wiegand RS232 RS485 USB Ethernet for office
Model: AC8030
Size: 86mm * 86mm * 38mm
Color: black
Material Science: PC+Tempered glass
Delivery time: According to customized requirements
Transaction mode: T/T, L/C, Credit Card, PayPal
Download
Wired Handheld barcode scanner-AC8030 AC8031
Product description
● Support non-contact ic cards, type A/B, M1 card.
● Support customized software according to customer’s requirements.
● Support customized software according to customer’s requirements.
● Suitable for such as control of the elevator, commuity, office, club, factory, school and so on.
Flexible, optional relay.
The 4th generation I-SUBPIXEL algorithm of intelligent access control card readers.
Product details
Product parameters
Model |
AC8030 |
AC8031 |
|
Scan CodePerformance |
Sensor |
640 X 480 CMOS@30fps |
|
View Angle |
Horizontal 63°, Vertical 51° |
||
DecodingCapability |
Default Open: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、Code39、Code93、CodaBar、QR Code、PDF417、DataMatrix |
||
Default Cloth: Interleaved 2 of 5、Industrial 25、Matrix 2 of 5、Code11、MSI Plessey、RSS-14、RSS-Limited、RSS-Expanded |
|||
Read Distance |
0 ~ 200mm（6-inch mobile phone, wechat QR payment code） |
||
Scan Angle |
Rotation: 360°, Pitch: ±60°, Deflection: ±50° |
||
Scan Mode |
Active / Passive, Support induction mode |
||
Precisions |
1D ≥ 5mil / 2D ≥ 10mil |
||
Symbol Contrast |
≥ 25% |
||
Scan Card Support |
ISO14443A/B, Mifare card |
||
Scan Code Feedback |
Buzzer; The green light indicates code scanning |
||
PhysicalParameters |
Weight |
100g |
|
Dimensions |
86mm * 86mm * 38mm |
||
Material |
PC+Tempered glass |
||
Interface |
Wiegand, RS232, RS485, USB |
Ethernet (Blue light indication) |
|
Prompt Mode |
LED prompt, Buzzer |
||
Voltage |
DC 12V (5V-32V), USB 5V |
||
Current |
< 160mA 12V |
||
Environmental light |
0-80000Lux |
||
IP Protection |
Front IP54 |
||
