MCMI 1d 2d Codes Reader Bar Code Scanner Module TTL-232 USB
Model: SE4320
Size: 22mmL * 11.5mmW * 15.9mmH
Color: black
Material Science: PC+ABS
Delivery time: According to customized requirements
Transaction mode: T/T, L/C, Credit Card, PayPal
Download
Wired Handheld barcode scanner-SD5230
Product description
● High performance 1D barcode scanner engine.
● Widely used for ring barcode scanner, neck barcode scanner, Bluetooth pocket portable code reader etc.
● With strong reading ability, It can provide excellent scanning code reading performance in a variety
of lighting environments (including completely dark environment, strong light), large temperature
and humidity range. It can also adapt to a variety of harsh and complex working environment, such
as: impact, vibration and strong exposure.
Product parameters
|
Model |
SE4320 |
|
|
Scan Code Performance |
Image (Pixels) Sensor |
1600 |
|
Light Source |
Fill Light: Red LED |
|
|
View Angle |
Horizontal 42° |
|
|
Decoding Capability |
1D: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、Code39、Code93、CodaBar、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code11、MSI-Plessey、Standard 2 of 5、Plessey、China Post、GS1 Databar (RSS-Expand, RSS-Limited, RSS-14) |
|
|
Depth of Field |
Code39: 50 ~ 110mm （5mil） EAN13: 40 ~ 310mm（13mil） Code128: 30 ~ 430 mm（15mil） |
|
|
Scan Angle |
Rotation: ±30°, Pitch: ±60°, Deflection: ±60° |
|
|
Scan Mode |
Continuous mode, Induction mode, Manual mode, Command-triggered mode |
|
|
Reading Speed |
Up to 100 times/second (static decoding without interval) |
|
|
Precisions |
≥ 4mil/0.1mm (PCS90%, CODE 39) |
|
|
Symbol Contrast |
≥ 10% |
|
|
Physical Parameters |
Weight |
< 5g |
|
Dimensions |
22mmL * 11.5mmW * 15.9mmH |
|
|
Interface |
USB VCP / USB HID-KBW (Default) / USB HID-POS / TTL-232 |
|
|
Prompt Mode |
LED prompt, Buzzer (External connection available) |
|
|
Voltage |
DC +3.3V (±5%) |
|
|
Current |
180mA |
|
